Svivlo Draken ONE
Draken ONE is a lightweight baitcasting reel designed for bass, perch, and multi-species fishing where control, balance, and consistency over long sessions matter. It’s well suited for techniques such as jigs, crankbaits, and fishing around cover, where changing conditions and repeated casts are part of the day.
Powered by the CastGuard™ system, Draken ONE is designed to behave more consistently as fishing conditions change — reducing the need for constant adjustment when lure weights, wind, or casting tempo vary. Instead of relying on frequent tuning or thumb control, the reel works quietly in the background to help maintain a steady casting rhythm.
Balanced for all-day use, Draken ONE supports a wide range of everyday techniques without adding unnecessary complexity. The focus is on predictable behavior on the water, so attention stays on fishing rather than managing the reel.
€239.00 (excl VAT)
| Size | 100-150 |
| Fresh water/salt water proof | Yes, with proper maintenance |
| Situational aware cast brake | Yes, CastGuard 2.0 |
| Adjustable centrifugal brake | No |
| Adjustable magnetic brake | No |
| Adjustable thumbing | No |
| Adjustable digital brake (DC) | No |
| Requires charging | No |
| External or internal adjustments | No |
| Color | Midgaard Dunkel matte black |
| Sideplate material | Carbon fiber (CF40) |
| Frame material | Carbon fiber (CF40) |
| Drag brake | Carbon fiber plates, 3pcs |
| Stainless steel ball bearings | Yes, double shielded |
| Main gear | Hamai cut brass |
| Pinion | Hamai cut brass |
| Handle bar | Aluminum with extra large EVA-knobs |
| Engineered for showroom evaluation | No |
| Engineered for real usage | Yes |
| Model | Draken ONE Left | Draken ONE Right |
|---|---|---|
| SKU | DRK1-CG2-7.3-LH | DRK1-CG2-7.3-RH |
| Cast Control System (CCS) | CastGuard 2.0 | CastGuard 2.0 |
| Handle position | Left side | Right side | Handle Shaft Dimension | 8x5mm | 8x5mm |
| Ball bearings | 9 + 2RB | 9 + 2RB |
| Ball bearing type | Double shielded – Stainless steel | Double shielded – Stainless Steel |
| Gear ratio | 7.3:1 | 7.3:1 |
| Line retrieval per rotation (cm/inch) | 78/30.7 | 78/30.7 |
| Line capacity (mm/m)
Please refer to the mono |
0.10/700 0.15/500 0.20/300 0.29/150 |
0.10/700 0.15/500 0.20/300 0.29/150 |
| Spool | Aluminum | Aluminum |
| Max drag brake (kg/lbs) | 7/15.4 | 7/15.4 |
| Drag brake material | Multi disc carbon fiber | Multi disc carbon fiber |
| Drag brake type | Star | Star |
| Weight (g/oz) | 211/7.4 | 211/7.4 |
| Diameter (mm) | PE Rating | Breaking Strength (lbs) | Breaking Strength (kg) |
| 0.08 mm | PE 0.4 | 4–6 lbs | 1.8–2.7 kg |
| 0.10 mm | PE 0.6 | 6–8 lbs | 2.7–3.6 kg |
| 0.14 mm | PE 0.8 | 8–12 lbs | 3.6–5.4 kg |
| 0.20 mm | PE 1.2 | 20–30 lbs | 9.1–13.6 kg |
| 0.205 mm | PE 1.5 | 22–32 lbs | 10.0–14.5 kg |
| 0.27 mm | PE 3.0 | 35–47 lbs | 15.9–21.2 kg |
| 0.32 mm | PE 4.0 | 45–57 lbs | 20.6–25.8 kg |
| 0.36 mm | PE 5.0 | 53–69 lbs | 24.0–31.2 kg |
| 0.40 mm | PE 6.0 | 65–80 lbs | 29.5–36.3 kg |
How much 0.4 mm monofilament is needed to back the spool when you have 150 m of braided line?
| 150 m Braided Line Diameter (mm) | Monofilament Backing (0.4 mm) in Meters | Monofilament Backing (0.4 mm) in Yards |
| 0.08 | 65 m | 70 yards |
| 0.10 | 60 m | 65 yards |
| 0.15 | 50 m | 55 yards |
| 0.20 | 30 m | 35 yards |
| 0.205 | 30 m | 35 yards |
| 0.27 | 0 m | 0 yards |
| 0.29 | N/A (reduce to ~132 m braided) | N/A |
| 0.32 | N/A (reduce to ~109 m braided) | N/A |
| 0.36 | N/A (reduce to ~86 m braided) | N/A |
| 0.40 | N/A (reduce to ~70 m braided) | N/A |
-
Material Difference: Braided line and monofilament have different densities and packing efficiencies. Braided line is typically more compact due to its weave, while monofilament might pack less densely, especially if it has memory or stiffness. This can reduce the effective capacity slightly (e.g., by 10–20%).
-
Safety Margin: Anglers often leave a small gap (1–2 mm from the flange) to prevent overfilling and tangles.
- All numbers are approximate and should be used as a guide and not as exact measurements.
Draken ONE is designed to behave predictably as conditions change, reducing interruptions caused by lure weight, wind, or casting tempo. Instead of constant manual tuning, the reel maintains a steady casting rhythm once fishing begins.
CastGuard™ is a patented mechanical system that manages spool behavior during the cast rather than relying on static brake settings. It works automatically in the background to reduce the need for frequent adjustment as conditions change.
CastGuard™ is a patented mechanical system that manages spool behavior during the cast rather than relying on static brake settings. It works automatically in the background to reduce the need for frequent adjustment as conditions change.
The brass drive gear is built for strength and long-term durability under repeated load. Its wear resistance and corrosion protection support smooth operation with minimal maintenance over time.
The brass drive gear is built for strength and long-term durability under repeated load. Its wear resistance and corrosion protection support smooth operation with minimal maintenance over time.
The carbon reinforced frame balances low weight with high rigidity, helping reduce fatigue while maintaining stable gear alignment. Its corrosion resistance supports durability in wet and variable fishing conditions.
The carbon reinforced frame balances low weight with high rigidity, helping reduce fatigue while maintaining stable gear alignment. Its corrosion resistance supports durability in wet and variable fishing conditions.
